Better Parallax In Flutter Carousels

My attempt to get you to pick apart the Material Design UX effects and see where you can brand.

So how about better parallax than say doing the offset in a pageview? I am talking about this type of parallax:





  So let me get into comparing it to offset.

  Offset vs Transform Parallax

   So this is what parallax looks like in pageview using the offset:



  Whereas this is using Transform.translate in the horizontal direction:



 In that mix is some smart scaling to avoid clipping the image. Let me step through the code.

Parallax Item Of Carousel Code

Logic wise, the parent PageView computes the local parallax amount from pageIndex - index. With the rest being how to set specific parameters of the background parallax image and the front label text widget which are both placed in a stack widget:

This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters. Learn more about bidirectional Unicode characters

Show hidden characters

	/// A widget representing an individual item within the parallax swiper.
	class _SwiperItem extends StatelessWidget {
	/// Creates a `_SwiperItem` widget to display an individual item in the parallax swiper.
	///
	/// Parameters:
	///
	/// - [image] The URL of the image to display within the item.
	/// - [parallaxFactor] The parallax factor that controls the intensity of the parallax effect.
	/// - [value] The value that determines the position of the item within the swiper.
	/// - [padding] The padding applied to the item.
	/// - [child] The foreground widget to display within the item.
	/// - [foregroundFadeEnabled] A flag that determines whether the foreground widget should fade in and out.
	/// - [backgroundZoomEnabled] A flag that determines whether the background image should zoom in and out.
	const _SwiperItem({
	required this.image,
	required this.parallaxFactor,
	required this.value,
	required this.padding,
	this.child,
	this.foregroundFadeEnabled = true,
	this.backgroundZoomEnabled = true,
	});
	/// The URL of the image to display within the item.
	final String image;
	/// The parallax factor that controls the intensity of the parallax effect.
	final double parallaxFactor;
	/// The value that determines the position of the item within the swiper.
	final double value;
	/// The padding applied to the item.
	final EdgeInsets padding;
	/// The foreground widget to display within the item.
	final Widget? child;
	/// A flag that determines whether the foreground widget should fade in and out.
	final bool foregroundFadeEnabled;
	/// A flag that determines whether the background image should zoom in and out.
	final bool backgroundZoomEnabled;
	@override
	Widget build(BuildContext context) {
	// Calculate the width of the item based on the device's screen width,
	// clamped between 200.0 and 500.0.
	final width = MediaQuery.sizeOf(context).width.clamp(200.0, 500.0);
	// Create a linear interpolation between 0.0 and 1.0 based on the value of the `value` variable.
	final tween = Tween<double>(begin: 0.0, end: 1.0).transform(value);
	// Calculate the translation offset of the foreground widget.
	final foregroundOffset = Offset(-(tween * pow(parallaxFactor, 2.2)), 0);
	// Calculate the opacity of the foreground widget to create a fade effect if enabled.
	final foregroundOpacity = foregroundFadeEnabled ? 1 - tween.clamp(0.0, 1.0) : 1.0;
	// Calculate the translation offset of the backround widget.
	final backgroundOffset = Offset(tween * pow(parallaxFactor, 2), 0);
	// Calculate the scale factor of the background widget to create a zoom effect if enabled.
	final scale = backgroundZoomEnabled ? 1.0 + (value.abs() * 0.15) * 1.1 : 1.0;
	return Container(
	padding: padding,
	width: width,
	child: ClipRRect(
	// Apply rounded corners to the container.
	borderRadius: BorderRadius.circular(16),
	child: Stack(
	children: [
	Transform.translate(
	// Apply a horizontal translation (parallax effect) to the image.
	offset: backgroundOffset,
	child: Transform.scale(
	// Apply a scale transformation to the image to prevent clipping when translated.
	scale: 1.2 * scale,
	child: LayoutBuilder(builder: (context, constraints) {
	return Image.asset(
	image,
	width: constraints.maxWidth,
	height: constraints.maxHeight,
	fit: BoxFit.cover,
	);
	}),
	),
	),
	// Foreground widget
	if (child != null)
	AnimatedOpacity(
	opacity: foregroundOpacity,
	duration: const Duration(milliseconds: 100),
	child: Transform.translate(
	offset: foregroundOffset,
	child: child,
	),
	),
	],
	),
	),
	);
	}
	}

view raw swiper_snippet.dart hosted with ❤ by GitHub

Now, in showing the full PageView code, you will see that the scrollable configuration physics is set locally. That is because of the interference with text selection if we set it globally:

This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters. Learn more about bidirectional Unicode characters

Show hidden characters

	// Copyright 2023 Fredrick Allan Grott. All rights reserved.
	// Use of this source code is governed by a BSD-style
	// license that can be found in the LICENSE file.
	import 'dart:math';
	import 'package:final_carousel/drag_scroll_behavior_configuration.dart';
	import 'package:flutter/material.dart';
	/// A widget that displays a parallax swiper with multiple images.
	///
	/// The [ParallaxSwiper] widget allows you to create a horizontal swiper that
	/// displays a list of images with parallax scrolling effects. You can customize
	/// its behavior by providing a list of image URLs, enabling or disabling
	/// drag-to-scroll functionality, setting the viewport fraction, adjusting padding,
	/// controlling the parallax factor, and toggling foreground fading and background zoom.
	///
	/// Example 1: Using [ParallaxSwiper] with Default Values (Foreground Fading and Background Zoom Enabled):
	///
	/// ```dart
	/// ParallaxSwiper(
	/// images: [
	/// 'image_url_1.jpg',
	/// 'image_url_2.jpg',
	/// 'image_url_3.jpg',
	/// ],
	/// )
	/// ```
	///
	/// Example 2: Using [ParallaxSwiper] with No Foreground Fading and No Background Zoom:
	///
	/// ```dart
	/// ParallaxSwiper(
	/// images: [
	/// 'image_url_1.jpg',
	/// 'image_url_2.jpg',
	/// 'image_url_3.jpg',
	/// ],
	/// dragToScroll: true,
	/// viewPortFraction: 0.85,
	/// padding: EdgeInsets.all(16.0),
	/// parallaxFactor: 10.0,
	/// foregroundFadeEnabled: false, // Disable foreground image fading.
	/// backgroundZoomEnabled: false, // Disable background image zooming.
	/// )
	/// ```
	///
	/// @author Fredrick Allan Grott
	class ParallaxSwiper extends StatefulWidget {
	const ParallaxSwiper({
	super.key,
	required this.images,
	this.dragToScroll = true,
	this.viewPortFraction = 1,
	this.padding = const EdgeInsets.all(8.0),
	this.parallaxFactor = 10.0,
	this.foregroundFadeEnabled = true,
	this.backgroundZoomEnabled = true,
	});
	/// A list of image URLs to display in the parallax swiper.
	final List<String> images;
	/// A flag that determines whether drag-to-scroll functionality is enabled.
	final bool dragToScroll;
	/// The fraction of the viewport that each item occupies.
	final double viewPortFraction;
	/// The padding applied to each image.
	final EdgeInsets padding;
	/// The parallax factor that controls the intensity of the parallax effect.
	final double parallaxFactor;
	/// A flag that determines whether the foreground widget should fade in and out.
	final bool foregroundFadeEnabled;
	/// A flag that determines whether the background image should zoom in and out.
	final bool backgroundZoomEnabled;
	@override
	State<ParallaxSwiper> createState() => _ParallaxSwiperState();
	}
	/// The state class for the `ParallaxSwiper` widget, responsible for managing its behavior.
	class _ParallaxSwiperState extends State<ParallaxSwiper> {
	/// The controller for the [PageView].
	late final PageController controller;
	/// The raw index of the current page in the [PageView].
	double pageIndex = 0.0;
	/// Listener method for updating the current page index when the page changes.
	///
	/// This method is invoked when the page changes in the [PageView] controller.
	/// It updates the [pageIndex] state variable to reflect the current page index.
	void _indexChangeListener() {
	// Update the [pageIndex] when the page changes.
	setState(() => pageIndex = controller.page!);
	}
	/// Initializes the state of the widget.
	///
	/// This method is called when this widget is inserted into the tree and can be
	/// used for one-time initialization tasks. It creates a [PageController] with the
	/// specified `viewportFraction` and adds a listener [_indexChangeListener] to it.
	/// The listener will be called whenever the page changes. This method ensures that
	/// the controller's listener is added only after the widget is built by using
	/// `WidgetsBinding.instance.addPostFrameCallback`.
	@override
	void initState() {
	super.initState();
	controller = PageController(
	viewportFraction: widget.viewPortFraction,
	);
	// Add the index change listener to the controller after the frame is built.
	WidgetsBinding.instance.addPostFrameCallback((_) {
	controller.addListener(_indexChangeListener);
	});
	}
	/// Dispose method to release resources when the widget is removed from the tree.
	///
	/// This method removes the listener [_indexChangeListener] from the [controller]
	/// and disposes of the [controller] itself to prevent memory leaks and resource
	/// leaks. It should be called when the widget is no longer needed.
	@override
	void dispose() {
	// Remove the index change listener and dispose of the controller.
	controller
	..removeListener(_indexChangeListener)
	..dispose();
	super.dispose();
	}
	@override
	Widget build(BuildContext context) {
	return ScrollConfiguration(
	// Apply drag-to-scroll behavior if enabled, otherwise use the default scroll behavior.
	// Better to set this per the scrollable as then the other things like text fields, etc.
	// are not set gloabally which would then mess up those things just to get dragging of
	// this scrollable for both desktop and web.
	behavior: widget.dragToScroll ? DragScrollBehavior() : const ScrollBehavior(),
	child: PageView.builder(
	controller: controller,
	itemCount: widget.images.length,
	itemBuilder: (context, index) {
	// Calculate the parallax effect value based on the controller position.
	double value = controller.position.haveDimensions ? pageIndex - index : 0;
	return _SwiperItem(
	image: widget.images[index],
	value: value,
	padding: widget.padding,
	parallaxFactor: widget.parallaxFactor,
	foregroundFadeEnabled: widget.foregroundFadeEnabled,
	backgroundZoomEnabled: widget.backgroundZoomEnabled,
	// Replace it with your own widget if you want to display something other than text.
	child: Align(
	alignment: Alignment.center,
	child: Padding(
	padding: const EdgeInsets.all(8.0),
	child: Text(
	'Item $index',
	style: Theme.of(context).textTheme.headlineLarge!.copyWith(
	color: Colors.white,
	),
	),
	),
	),
	);
	},
	),
	);
	}
	}
	/// A widget representing an individual item within the parallax swiper.
	class _SwiperItem extends StatelessWidget {
	/// Creates a `_SwiperItem` widget to display an individual item in the parallax swiper.
	///
	/// Parameters:
	///
	/// - [image] The URL of the image to display within the item.
	/// - [parallaxFactor] The parallax factor that controls the intensity of the parallax effect.
	/// - [value] The value that determines the position of the item within the swiper.
	/// - [padding] The padding applied to the item.
	/// - [child] The foreground widget to display within the item.
	/// - [foregroundFadeEnabled] A flag that determines whether the foreground widget should fade in and out.
	/// - [backgroundZoomEnabled] A flag that determines whether the background image should zoom in and out.
	const _SwiperItem({
	required this.image,
	required this.parallaxFactor,
	required this.value,
	required this.padding,
	this.child,
	this.foregroundFadeEnabled = true,
	this.backgroundZoomEnabled = true,
	});
	/// The URL of the image to display within the item.
	final String image;
	/// The parallax factor that controls the intensity of the parallax effect.
	final double parallaxFactor;
	/// The value that determines the position of the item within the swiper.
	final double value;
	/// The padding applied to the item.
	final EdgeInsets padding;
	/// The foreground widget to display within the item.
	final Widget? child;
	/// A flag that determines whether the foreground widget should fade in and out.
	final bool foregroundFadeEnabled;
	/// A flag that determines whether the background image should zoom in and out.
	final bool backgroundZoomEnabled;
	@override
	Widget build(BuildContext context) {
	// Calculate the width of the item based on the device's screen width,
	// clamped between 200.0 and 500.0.
	final width = MediaQuery.sizeOf(context).width.clamp(200.0, 500.0);
	// Create a linear interpolation between 0.0 and 1.0 based on the value of the `value` variable.
	final tween = Tween<double>(begin: 0.0, end: 1.0).transform(value);
	// Calculate the translation offset of the foreground widget.
	final foregroundOffset = Offset(-(tween * pow(parallaxFactor, 2.2)), 0);
	// Calculate the opacity of the foreground widget to create a fade effect if enabled.
	final foregroundOpacity = foregroundFadeEnabled ? 1 - tween.clamp(0.0, 1.0) : 1.0;
	// Calculate the translation offset of the backround widget.
	final backgroundOffset = Offset(tween * pow(parallaxFactor, 2), 0);
	// Calculate the scale factor of the background widget to create a zoom effect if enabled.
	final scale = backgroundZoomEnabled ? 1.0 + (value.abs() * 0.15) * 1.1 : 1.0;
	return Container(
	padding: padding,
	width: width,
	child: ClipRRect(
	// Apply rounded corners to the container.
	borderRadius: BorderRadius.circular(16),
	child: Stack(
	children: [
	Transform.translate(
	// Apply a horizontal translation (parallax effect) to the image.
	offset: backgroundOffset,
	child: Transform.scale(
	// Apply a scale transformation to the image to prevent clipping when translated.
	scale: 1.2 * scale,
	child: LayoutBuilder(builder: (context, constraints) {
	return Image.asset(
	image,
	width: constraints.maxWidth,
	height: constraints.maxHeight,
	fit: BoxFit.cover,
	);
	}),
	),
	),
	// Foreground widget
	if (child != null)
	AnimatedOpacity(
	opacity: foregroundOpacity,
	duration: const Duration(milliseconds: 100),
	child: Transform.translate(
	offset: foregroundOffset,
	child: child,
	),
	),
	],
	),
	),
	);
	}
	}

view raw parallax_swiper.dart hosted with ❤ by GitHub

So now I am left with the problem of how to animate and resize the non-active items.That probably requires an AnimatedBuilder than transforms keyed to the page position. But keep in mind that it can be any transform and not just the transform they used as an example in the description of the Material Design carousel in the design specification.

 For example, here would be the basic core of the code;

This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters. Learn more about bidirectional Unicode characters

Show hidden characters

	itemCount: cards.length,
	itemBuilder: (_, index) {
	if (!carouselController.position.haveDimensions) {
	return const SizedBox();
	}
	return AnimatedBuilder(
	animation: carouselController,
	builder: (_, __) => Transform.scale(
	scale: max(
	0.8,
	(1 - (carouselController.page! - index).abs() / 2),
	),
	child: cards[index],
	),
	);

view raw animated_snippet.dart hosted with ❤ by GitHub

I just have to modify the pagge view swiper one more time and incorporate the AnimatedBuilder and the transform I want to use.
